Ibm System X Processori

Lenovo Xeon Intel Silver 4314 processor 2.4 GHz 24 MB Box
Ibm System X Processori

1.343,29 EUR
(1kg = 5.127,06 EUR)
Shipping from 0,00 EUR*
Accessories
LENOVO
Shipping charges are minimized.
Ibm System X Processori 1Ibm System X Processori 2Ibm System X Processori 34 visitors
are looking at this item
Delivery to US in: Currently sold out but back in stock soon
Sales Rank: 0
Style: CPU Processors
Product No.: 2100621933

Compare with similar items

ITEMS
Ryzen 7 8700F Tray 5GHz MAX 8xCore 16xThread 24MB 65W
AMD Ryzen 9 7900 processor 3.7 GHz 64 MB L3 Box
AMD Ryzen 7 5700X3D processor 3 GHz 96 MB L3 Box
AMD Ryzen 9 5950X processor 3.4 GHz 64 MB L3
  "Amd-Ryzen 7 8700F Tray 5GHz MAX 8xCore 16xThread 24MB 65W-Amd-Hardware/Electronic" "Amd-AMD Ryzen 9 7900 processor 3.7 GHz 64 MB L3 Box-Amd-Hardware/Electronic" "Amd-AMD Ryzen 7 5700X3D processor 3 GHz 96 MB L3 Box-Amd-Hardware/Electronic" "Amd-AMD Ryzen 9 5950X processor 3.4 GHz 64 MB L3-Amd-Hardware/Electronic"

Item number2101174649210076922221010795162100165257
On offer since18.05.202404.01.202305.01.202414.11.2020
Price138,89 EUR267,99 EUR257,49 EUR225,19 EUR
Weight0.12kg0.85kg0.32kg0.24kg
ManufacturerAmdAmdAmdAmd
CategoryHardware/ElectronicHardware/ElectronicHardware/ElectronicHardware/Electronic
Processor familyAMD Ryzen? 7 AMD Ryzen? 9 AMD Ryzen? 7 AMD Ryzen? 9
Processor cores8 12 8 16
Processor socketSocket AM5 Socket AM5 Socket AM4 Socket AM4
Processor lithography4 nm5 nm7 nm7 nm
BoxNo Yes Yes Yes
Cooler includedNo Yes No No
Processor manufacturerAMD AMD AMD AMD
Processor model8700F 7900 5700X3D 5950X
Processor base frequency4.1 GHz3.7 GHz3 GHz3.4 GHz
Threads16 24 16 32
Processor boost frequency5 GHz5.4 GHz4.1 GHz4.9 GHz
Processor cache16 MB64 MB96 MB64 MB
Processor cache typeL3 L3 L3 L3
ITEMS
Ryzen 7 8700F Tray 5GHz MAX 8xCore 16xThread 24MB 65W
AMD Ryzen 9 7900 processor 3.7 GHz 64 MB L3 Box
AMD Ryzen 7 5700X3D processor 3 GHz 96 MB L3 Box
AMD Ryzen 9 5950X processor 3.4 GHz 64 MB L3
Thermal Design Power (TDP)65 W65 W105 W105 W
Memory types supported by processorDDR5-SDRAM DDR5-SDRAM DDR4-SDRAM DDR4-SDRAM
Memory clock speeds supported by processor3600,5200 MHz3600,5200 MHz2667,2933,3200 MHz3200 MHz
On-board graphics cardNo Yes No No
Discrete graphics cardNo No No No
On-board graphics card modelNot available AMD Radeon Graphics Not available Not available
Discrete graphics card modelNot available Not available Not available Not available
PCI Express slots version4.0 5.0 4.0 4.0
Market segmentDesktop Desktop Desktop Desktop
more featuresno informationno informationno informationamd-ryzen-9

Other interesting products in CPU Processors
Amd - AMD Ryzen 9 9900X processor 4.4 GHz 76 MB L2 & L3 Box
AMD Ryzen 9 9900X processor 4.4 GHz 76 MB ...
Amd

369,59 EUR
Intel - INTEL Core i3-14100T 2.7GHz FC-LGA16A 12M Cache Tray CPU (CM80715092103)
INTEL Core i3-14100T 2.7GHz FC-LGA16A 12M ...
Intel

136,79 EUR
Amd - Ryzen 9 9950x3d 5.7ghz Am5 16c/32t 170w 144mb Tray
Ryzen 9 9950x3d 5.7ghz Am5 16c/ 32t 170w 1...
Amd

617,29 EUR
Amd - AMD Ryzen 7 7800X3D Prozessor 4,2 GHz 96 MB L3
AMD Ryzen 7 7800X3D Prozessor 4, 2 GHz 96 ...
Amd

311,69 EUR
Amd - AM5 AMD Ryzen 9 9950X3D WOF 4,3GHz MAX Boost 5,7GHz 16xCore 144MB 170W
AM5 AMD Ryzen 9 9950X3D WOF 4, 3GHz MAX Bo...
Amd

643,29 EUR
Intel - Intel Core i5-14400F processor 20 MB Smart Cache
Intel Core i5-14400F processor 20 MB Smart...
Intel

103,29 EUR
Amd Gmbh - AMD Ryzen 5 3400G processor 3.7 GHz Box 4 MB L3
AMD Ryzen 5 3400G processor 3.7 GHz Box 4 ...
Amd Gmbh

66,49 EUR

Content:

Description:Intel Xeon Silver 4314 - 2.4 GHz - 16 cores - 32 threads - 24 MB cache memory - for ThinkAgile HX7530 Appliance, MX3530-H Hybrid Certified Node Group Processor Upgrades Manufacturer Lenovo Manufacturer Item No. 4XG7A63455 Model Intel Xeon Silver 4314 EAN/UPC 0889488531325 Product Description: Intel Xeon Silver 4314/2.4 GHz processor product type processor processor type Intel Xeon Silver 4314 (3rd gen) No. of cores 16 cores/32 threads Cache memory 24 MB processor number. 1 clock speed 2.4 GHz Max. Turbo clock speed 3.4 GHz Manufacturing process 10 nm Features Integrated Memory Controller, Intel Turbo Boost Technology 2.0, Intel Software Guard Extensions (SGX), Intel Optane DC Persistent Memory Supported Designed for ThinkAgile HX5530 Appliance 7Z82, HX5531 Certified Node 7Z84, HX7530 Appliance 7Z82, HX7531 Certified Node 7Z84, MX3530-H Hybrid Appliance 7D6B, MX3531-H Hybrid Certified Node 7D66, ThinkSystem SR650 V2 7D15, 7Z72, 7Z73 Detailed
Manufacturer No.: 4XG7A63455
Product Safety

Technical specifications

Language

Processor

BoxYes
Component forServer/workstation
Cooler includedNo
Processor ARK ID215269
Processor base frequency2.4 GHz
Processor boost frequency3.4 GHz
Processor cache24 MB
Processor codenameIce Lake
Processor cores16
Processor familyIntel Xeon Silver
Processor generation3rd Generation Intel® Xeon® Scalable
Processor lithography10 nm
Processor manufacturerIntel
Processor model4314
Processor operating modes64-bit
Processor socketLGA 4189
Processor threads32
System bus rate10.4 GT/s
Thermal Design Power (TDP)135 W

Operational conditions

Tcase86 °C

Weight & dimensions

Processor package size77.5 x 56.5 mm

Memory

ECCYes
Maximum internal memory supported by processor6.14 TB
Memory channelsOcta-channel
Memory clock speeds supported by processor2667 MHz
Memory types supported by processorDDR4-SDRAM

Graphics

Discrete graphics cardNo
Discrete graphics card modelNot available
On-board graphics cardNo
On-board graphics card modelNot available

Other features

Maximum internal memory6 TB

Processor special features

AVX-512 Fused Multiply-Add (FMA) units2
Intel 64Yes
Intel Software Guard Extensions (Intel SGX)Yes
Intel Trusted Execution TechnologyYes
Intel VT-x with Extended Page Tables (EPT)Yes
Intel Virtualization Technology (VT-x)Yes
Intel Virtualization Technology for Directed I/O (VT-d)Yes
Intel® AES New Instructions (Intel® AES-NI)Yes
Intel® Crypto AccelerationYes
Intel® Deep Learning Boost (Intel® DL Boost) on CPUYes
Intel® Hyper Threading Technology (Intel® HT Technology)Yes
Intel® Optane™ DC Persistent Memory SupportedYes
Intel® Platform Firmware Resilience SupportYes
Intel® Resource Director Technology (Intel® RDT)Yes
Intel® Speed Shift TechnologyYes
Intel® Total Memory EncryptionYes
Intel® Transactional Synchronization ExtensionsYes
Intel® Turbo Boost Technology2.0
Intel® Volume Management Device (VMD)Yes
Maximum Enclave Size Support for Intel® SGX8 GB
Mode-based Execute Control (MBE)Yes

Features

Commodity Classification Automated Tracking System (CCATS)G178966
Embedded options availableYes
Execute Disable BitYes
Export Control Classification Number (ECCN)5A992CN3
Market segmentServer
Maximum number of PCI Express lanes64
PCI Express slots version4.0
Scalability2S
Supported instruction setsSSE4.2, AVX, AVX 2.0, AVX-512

Technical details

Launch dateQ2'21
Memory speed (max)2667 MHz
Number of UPI links2
StatusLaunched
Supported memory typesDDR4-SDRAM
Target marketCloud Computing

Logistics data

Harmonized System (HS) code85423119

Packaging data

Package typeRetail box
